Description
Designed with vertical lift loader arms, its 1,000-lb rated operating capacity delivers category-crushing performance that’s an industry game-changer. The Dingo TX 1000 also offers increased reach at full height for maximum jobsite productivity. And speaking of productivity, an 81" (206 cm) hinge pin height allows the arms to clear the side of a 30-yard dumpster or one-ton truck. This lightweight, maneuverable machine packs unmatched strength and reach in a compact package for the ultimate working advantage.
Specifications
Manufacturer
Toro
Model
Dingo® TX 1000 Wide Track (22328)
Year
2025
Category
Buckets
Subcategory
Buckets
Air Filter
Two-stage, heavy-duty, remote
Cooling System
Liquid Cooled
Hydraulic Flow Auxilary
15.2 gpm
Hydraulic Flow Traction
13.3 gpm (each pump)
Hydraulic Pressure
3000 PSI
Loader Arms
Vertical Lift
Manufacturer's Gross HP Rating (HP)
24.8
Manufacturer's Gross HP Rating (kW)
18.5
Oil Capacity (liters)
5.7
Oil Capacity (quarts)
6
Rated Operating Capacity - 35% of Tip Capacity (kg)
453
Rated Operating Capacity - 35% of Tip Capacity (lbs)
1000
Reach – Fully Raised (cm)
62.2
Reach – Fully Raised (inches)
24.5
Reservoir Capacity (gallons)
10
Reservoir Capacity (liters)
37.8
RPM
2600
Tip Capacity (kg)
1392
Tip Capacity (lbs)
3071
Tracks
Sprocket-drive, 6 road wheels per side
Traction
Dual Hydrostatic Pump
Weight (kg)
1265
Weight (lbs)
2790
Wheelbase (inches)
41
Dump Angle
40 degrees
Dump Height (cm)
154.9
Dump Height (inches)
61
Hinge Pin Height (cm)
205.7
Hinge Pin Height (inches)
81
Max Operating Height (cm)
266.7
Max Operating Height (inches)
105
Overall Height (cm)
135.1
Overall Height (inches)
53.2
Overall Length w/bucket (cm)
255.7
Overall Length w/bucket (inches)
100.7
Overall Length w/o bucket (cm)
207.5
Overall Length w/o bucket (inches)
81.7
Overall Width (cm)
104.1
Overall Width (inches)
41
Track Length (inches)
127.6
Track Length(cm)
324.1
Track Width (cm)
24
Track Width (inches)
9.5
Displacement (cc)
1262
Displacement (cu in)
77
Engine Make
Kubota
Engine Model
D1305
Fuel Tank (gallons)
11.5
Fuel Tank (liters)
44
Fuel Type
Diesel
Ground Clearance (cm)
15.2
Ground Clearance (inches)
6
Ground Pressure
3.6 psi
Ground Speed Forward (mph)
4
Ground Speed Foward (km/h)
7.6
Ground Speed Reverse (km/h)
7.6
Ground Speed Reverse (mph)
4
