Description
Designed to give you more power in a compact package, the Toro® Dingo® TX 700 expands labor savings beyond just homeowner projects. This no-nonsense workhorse packs 700 lbs of rated operating capacity in a smaller footprint, so it’s ideal for projects where homeowners and contractors are working in confined spaces.
Specifications
Manufacturer
Toro
Model
Dingo® TX 700 Narrow Track (22351)
Year
2025
Category
Grapples
Subcategory
Grapples
Air Filter
Remote single element
Hydraulic Flow Auxilary
13.7 gpm
Hydraulic Flow Traction
14.5 gpm (each pump)
Hydraulic Pressure
3,000 psi
Loader Arms
Radial
Manufacturer's Gross HP Rating (HP)
24.5
Manufacturer's Gross HP Rating (kW)
18
Oil Capacity (liters)
3.4
Oil Capacity (quarts)
3.6
Rated Operating Capacity - 35% of Tip Capacity (kg)
346
Rated Operating Capacity - 35% of Tip Capacity (lbs)
764
Reach – Fully Raised (cm)
78.7
Reach – Fully Raised (inches)
31
Reservoir Capacity (gallons)
10
Reservoir Capacity (liters)
37.9
Tip Capacity (kg)
989
Tip Capacity (lbs)
2182
Tracks
Camso B-Tread
Traction
Dual Hydrostatic Pump
Weight (kg)
1140
Weight (lbs)
2514
Wheelbase (inches)
39
Dump Angle
42 degrees
Dump Height (cm)
134.4
Dump Height (inches)
52.9
Hinge Pin Height (cm)
186.7
Hinge Pin Height (inches)
73.5
Max Operating Height (cm)
246.4
Max Operating Height (inches)
97
Overall Height (cm)
140.5
Overall Height (inches)
55.3
Overall Length w/bucket (cm)
261.1
Overall Length w/bucket (inches)
102.8
Overall Length w/o bucket (cm)
208.3
Overall Length w/o bucket (inches)
82
Overall Width (cm)
86.9
Overall Width (inches)
34.2
Track Length (inches)
126.6
Track Length(cm)
321.6
Track Width (cm)
13.7
Track Width (inches)
5.4
Engine Make
Yanmar
Engine Model
3TNV80F
Fuel Tank (gallons)
5.5
Fuel Tank (liters)
20.8
Fuel Type
Diesel
Ground Clearance (cm)
13.3
Ground Clearance (inches)
5.25
Ground Pressure
6.4 psi
Ground Speed Forward (mph)
4.5
Ground Speed Foward (km/h)
7.2
Ground Speed Reverse (km/h)
7.2
Ground Speed Reverse (mph)
4.5
