Description
The Snorkel S2770BE offers the capabilities of the S2770RT compact rough terrain scissor lift with a bi-energy power system. Highly versatile, use the diesel engine for outdoor work, or switch to zero emission battery power for indoor tasks. Non-marking, high grip tires, a roll-out deck extension and auto-level hydraulic outriggers come as standard.
Specifications
Manufacturer
Snorkel
Model
S2770BE
Year
2025
Category
Material Handling Equipment
Subcategory
Scissor Lifts
Min height (guardrails folded)
1.83m
Overall width
1.8m
Overall length
3.4m
Tires
27 x 10.5 - 15 foam filled non marking
Max working height
10.1m
Platform size (stowed)
1.6m x 2.8m
Platform size (extended)
1.6m x 4.0m
Deck extension length
1.2m
Ground clearance
330mm
Max drive height
8.23m
Max drive speed (elevated)
0.5km/h
Max drive speed (stowed)
4.5km/h
Raise / lower time
26 / 30 seconds
Gradeability (batteries)
25%
Inside turning radius
2.7m
Outside turning radius
5.0m
Controls
proportional joystick
Drive system
4 wheel drive
Power source
Kubota D-902 water cooled diesel 22.5 hp - Tier 4 Final & 4 x 6v 305Ah batteries
Weight
3,186kg
Max platform height
8.1m
Stowed height
2.61m
Max wind speed
12.5m/s
Gradeability (engine)
35%
