Description
Equipped with the Toro designed 4-Paw®, independent 4-wheel drive system, the Dingo® 323 at 3000 psi (206.7 bar) offers incredible power and durability. Delivering 10.8 gpm (40.9 lpm) of hydraulic power with this 23 hp (17.2 kw) Kohler engine will guarantee jobsite productivity.
Specifications
Manufacturer
Toro
Model
Dingo® 323 Mini Skid Steer (22318)
Year
2025
Category
Skid Steers
Subcategory
Mini Skid Steers
Dump Height
47 in / 119.3 cm
Ground Clearance
5.8 in / 14.7 cm
Height
48.7 in / 123.7 cm
Hinge Pin Height
66 in / 167.6 cm
Length
62 in / 157.5 cm
Length - With Bucket
82.2 in / 208.8 cm
Max Operating Height
91.2 in / 231.6 cm
Reach - Fully Raised
28 in / 71.1 cm
Track Length
96.6 in / 245.3 cm
Track Width
5.9 in / 14.9 cm
Wheelbase
28 in / 71.1 cm
Width - With Narrow Tires
35 in / 88.9 cm
Width - With Standard Tires
40.5 in / 102.8 cm
Ground Speed - Forward
Up to 3.7 mph / 6.1 km/h
Ground Speed - Reverse
Up to 3.7 mph / 6.1 km/h
Engine Discplacement
674 cc (41 cu in)
Engine Horsepower
25 hp (18.6 kW) @ 3,600 rpm
Engine Make
Kohler
Engine Model
Command Series CH23
Air Filter
Two-stage, heavy-duty, remote
Cooling System
Air Cooled
Dump Angle
34 deg
Fuel Tank
11.2 gal / 42.4 L
Fuel Type
Gasoline
Hydraulic High Flow
10.8 GPM
Hydraulic High-Flow Hydraulic Circuit
10.8 GPM
Hydraulic Low Flow
4 GPM
Hydraulic Pressure
3,250 PSI
Oil Capacity
2 qt / 1.9 L
Rated Operating Capacity*
515 lbs / 233.6 kg
Reservoir Capacity
17 gal / 6.4 L
Tip Capacity
1,030 lbs / 467 kg
Weight
1,567 lbs / 711 kg
