Description
JLG 400S
Specifications
Manufacturer
JLG
Model
400S
Year
2026
Category
Aerial Work Platforms
Subcategory
Telescopic Boom Lift
Auxiliary Power
12 Volts DC
Capacity - Fuel Tank
22 gal / 83.28 L
Engine Type - Diesel
Deutz D2.9L4 Tier 4 Final 49 hp 36.4 kW
Engine Type - Dual Fuel
GM Vortec 3000 MPFI 82 hp 61 kW
Drive Speed - 4WD
4.5 mph / 7.24 km/h
Gradeability - 4WD
45 %
Platform Capacity - Restricted
1000 lb / 453.59 kg
Platform Capacity - Unrestricted
600 lb / 272.16 kg
Swing
360 Degrees
Swing Type
Continuous
Capacity - Hydraulic Reservoir
36 gal / 136.27 L
Maximum Ground Bearing Pressure
58 psi / 4.06 Kg/cm2
Machine Weight
14520 lb / 6586.16 kg
Turning Radius - Inside
6 ft 5 in / 1.96 m
Turning Radius - Outside
15 ft 8 in / 4.78 m
Ground Clearance
1 ft / 0.31 m
Machine Height
8 ft 1 in / 2.47 m
Machine Length
24 ft 10 in / 7.57 m
Transport Length
24 ft 10 in / 7.57 m
Machine Width
7 ft 7 in / 2.31 m
Platform Dimension A
3 ft / 0.91 m
Platform Dimension B
8 ft / 2.44 m
Tailswing
2 ft 10 in / 0.86 m
Tire Size
12 x 16.5 Foam Filled Lug Tread Tires
Horizontal Outreach
33 ft 6 in / 10.21 m
Platform Height
40 ft / 12.19 m
