Description
Working on a low-speed job site where stability, reach, and power are top priorities for your machinery? Then the TH10-55 M74 is the machine you're looking for. It has the power that demanding jobs require but without the added stress and expense of having to maintain DEF fluid levels. Offering 10,000 lbs. of lifting capacity with a long boom, this Telescopic Handler is perfect for staging bricks and bulky loads of lumber on construction sites. And it can move at all boom levels to facilitate aligning of material positioning thanks to its upgraded stabilization system. Still interested in avoiding DEF fluid costs without sacrificing the strength you depend on? Then it's time to let the TH10-55 M74 do what it was built for; help you finish tough jobs in rough environments with less effort.
Specifications
Manufacturer
Gehl
Model
TH10-55 M74 - NEW
Year
2026
Category
Telehandlers
Subcategory
Construction Telehandlers
max capacity
10000 lb
max lifting height
55 ft 7 in
max outreach
42 ft 3 in
Lifting
16 s
Lowering
11 s
Extension
18 s
Retraction
16 s
Crowd
4 s
Dump
6 s
Engine brand
Deutz
Engine norm
Tier 4 final
Engine model
TCD 3.6 L4
Number of cylinders / Capacity of cylinders
4 - 220 in³
I C Engine power rating - Power (kW)
74 Hp / 55 kW
max torque / Engine rotation
288 ft/lbs @ 2300 rpm
Transmission type
Powershift
Number of gears (forward / reverse)
5/3
max travel speed
19 mi/h
Parking brake
SAHR
Service brake
Wet disc brakes
Hydraulic pump type
Axial piston
Hydraulic flow / Pressure
40 US gpm-4000 PSI
Engine oil
2 US gal
Hydraulic oil
42 US gal
Fuel tank
38 US gal
Noise at driving position (LpA)
80 dB
Steering wheels (front / rear)
2/2
Drive wheels (front / rear)
2/2
Controls
Joystick
Overall length to carriage
21 ft
Overall length (with forks)
25 ft
Overall width
8 ft 4 in
Overall height
8 ft 6 in
Wheelbase
11 ft 6 in
Ground clearance
1 ft 7 in
Overall cab width
3 ft 1 in
Tilt-up angle
34 °
Tilt-down angle
96 °
External turning radius
12 ft 9 in
Overall weight
30300 lb
Tyres type
Pneumatic
Forks length / width / section
48 in x 5 in / 2 in
Frame levelling longitudinal +/-
10 °
