Description
The Snorkel TM16E delivers the tallest working height in Snorkel’s line of self-propelled telescopic mast lifts. Featuring an electric drive system, this mast lift offers longer duty cycles on the job. Smooth proportional controls allows for precise positioning where needed most.
Specifications
Manufacturer
Snorkel
Model
TM16E
Year
2026
Category
Material Handling Equipment
Subcategory
Mast Lifts
Overall length
1.37m
Overall width
0.76m
Max working height
6.87m
Max platform height
4.87m
Platform size (stowed)
0.68m x 0.99m
Platform size (extended)
0.68m x 1.5m
Deck extension length
0.51m
Stowed height
1.98m
Ground clearance
76mm
Platform capacity (SWL)
227kg
Max drive height
4.87m
Max wind speed
0m/s
Max drive speed (elevated)
0.6km/h
Max drive speed (stowed)
4.0km/h
Raise / lower time
12.5 / 10.5 seconds
Max operating slope (side to side)
1.5º
Max operating slope (front to back)
1.5º
Inside turning radius
0m
Outside turning radius
1.4m
Tires
323mm non-marking rubber
Controls
proportional
Parking brake
2 wheel, spring-applied, electric release
Drive system
dual DC motors
Power source
24V 220Ah batteries
Battery charger
20 amp
Weight
1,105kg
Gradeability
25%
