Description
The Snorkel UL40 push-around mast lift is an easy and efficient work platform for indoor use. Fitted with outriggers as standard, the mast lift is also equipped with a patented telescopic Girder Lock mast for safe and stable work at height. Compact dimensions and a lightweight design easily fit through doorways for portability.
Specifications
Manufacturer
Snorkel
Model
UL40
Year
2025
Category
Material Handling Equipment
Subcategory
Mast Lifts
Overall length
1.32m
Overall width
0.74m
Weight (AC)
470kg
Max working height
14.1m
Max platform height
12.1m
Platform length
0.56m
Stabilizer footprint
2.95m x 2.85m
Tilt back length
2.99m
Tilt back height
2.0m
Stowed height
2.90m
Platform capacity (SWL)
136kg
Raise / lower time
60 / 40 sec
Controls
Push button
Wall access
736mm
Power source (AC)
120/220V AC 50HZ
Power source (DC)
1 x 12V 105Ah battery
Weight (DC)
500kg
