Description
The Snorkel S4726E electric scissor lift is designed to handle the heavy loads. With a high lift capacity and spacious platform featuring roll-out extension deck, the S4726E can handle most applications. Constructed from heavy-duty steel, and designed for a long working life, the S4726E delivers a low total cost of ownership.
Specifications
Manufacturer
Snorkel
Model
S4726E
Year
2025
Category
Material Handling Equipment
Subcategory
Scissor Lifts
Overall width
1.19m
Overall length (with step)
2.3m
Overall length (without step)
2.26m
Max platform height
7.8m
Stowed height
2.3m
Max working height
9.8m
Deck extension length
1.21m
Ground clearance (stowed)
66mm
Ground clearance (elevated)
19mm
Platform capacity (SWL)
454kg
Max wind speed
12.5m/s
Max drive height
7.8m
Max drive speed (elevated)
0.6km/h
Max drive speed (stowed)
3.2km/h
Raise / lower time
50 / 58 seconds
Inside turning radius
.25m
Outside turning radius
2.41m
Tires
15 x 5 non-marking rubber
Controls
proportional
Drive system
2 wheel drive
Power source
24V DC battery electric
Charger
90 - 240V, 25amp
Weight
2,250kg
Gradeability
25%
Min height (guardrails folded)
1.85m
Platform size (stowed)
1.09m x 2.14m
Platform size (extended)
1.09m x 3.36m
