Description
The Snorkel S4732E electric scissor lift offers the highest lift height in the line. A spacious roll-out deck extension with saloon-door style entry gates maximizes the platform working area. Deep cycle batteries ensure the lift works as long as you do, and a robust all-steel construction means it will keep on working for years to come too.
Specifications
Manufacturer
Snorkel
Model
S4732E
Year
2025
Category
Material Handling Equipment
Subcategory
Scissor Lifts
Overall width
1.19m
Overall length (with step)
2.3m
Overall length (without step)
2.26m
Max platform height
9.8m
Stowed height
2.39m
Max working height
11.8m
Deck extension length
1.21m
Ground clearance (stowed)
66mm
Ground clearance (elevated)
19mm
Platform capacity (SWL)
350kg
Max wind speed
12.5m/s
Max drive height
9.8m
Max drive speed (elevated)
0.6km/h
Max drive speed (stowed)
3.2 km/h
Raise / lower time
50 / 58 seconds
Inside turning radius
.25m
Outside turning radius
2.41m
Tires
15 x 5 non-marking rubber
Controls
proportional
Drive system
2 wheel drive
Power source
24V DC battery electric
Charger
90 - 240V, 25amp
Weight
2,693kg
Gradeability
25%
Min height (guardrails folded)
1.94m
Platform size (stowed)
1.09m x 2.14m
Platform size (extended)
1.09m x 3.36m
