Description
The Snorkel SL30RT Speed Level sigma boom lift makes the grade. Automatic self-leveling without outriggers offers a stable platform that can level up to 13° from side-to-side and up to 9° from front-to-back. Drivable at full height on powerful 4-wheel drive, the SL30RT tackles all terrains with ease, even on compound slopes.
Specifications
Manufacturer
Snorkel
Model
SL30RT
Year
2025
Category
Material Handling Equipment
Subcategory
Speed Level
Max working height
11.0m
Max platform height
9.0m
Overall width
2.13m
Stowed height
2.6m
Overall length
4.3m
Min height (guardrails folded)
1.7m
Platform size (stowed)
1.72m x 4.23m
Axle ground clearance
195mm
Chassis ground clearance
305mm
Max drive height
9.0m
Inside turning radius
3.9m
Outside turning radius
5.64m
Weight
3,400kg
Platform capacity (SWL)
590kg
Max wind speed
12.5m/s
Raise / lower time
24 / 36 seconds
Power source
Kubota D-902 water-cooled deisel engine - Teir 4 final
Tires
26 x 12.00 - 12 foam filled
Max drive speed (elevated)
0.8km/h
Max drive speed (stowed)
6.8km/h
Controls
proportional joystick
Drive system
4 wheel drive with hydraulic motors & flow dividers
Gradeability
50%
Max leveling (front to rear)
9°
Max leveling (side to side)
13°
