Description
The Snorkel 600S all-terrain telescopic boom lift is designed for any environment. A diesel engine and high torque drive motor deliver high performance in rough terrain. All-proportional boom functions and platform rotation also allow for ease of operation.
Specifications
Manufacturer
Snorkel
Model
600S
Year
2026
Category
Material Handling Equipment
Subcategory
Boom Lifts
Overall length
9.2m
Transport length
9.2m
Overall Height
2.52m
Transport width
2.46m
Weight
11,430kg
Auxiliary power unit
12V DC
Tires
355/55 D625 foam filled lug
Max working height
20.3m
Max platform height
18.3m
Max horizontal reach
16
Stowed height
2.51m
Ground clearance
340mm
Max drive height
18.4m
Max wind speed
12.5m/s
Max drive speed (elevated)
0.96km/h
Max drive speed (stowed)
5.6km/h
Raise / lower time
50 / 50 seconds
Inside turning radius
3.06m
Outside turning radius
5.21m
Controls
proportional drive, raise, slew, extend, jib and platform rotate
Drive system
4 wheel drive
Power source
Cummins 65hp (47.8kW) turbo diesel, Deutz T4F, stage V
Platform size
2.44m x 0.91m
Platform capacity - unrestricted
272kg
Superstructure rotation
360° continuous
Platform capacity - restricted
454kg
Tailswing
1.2m
