Description
The robust and reliable Snorkel AB60J articulating boom lift easily reaches up and over obstacles. Designed tough for the rental industry, it is simple to operate and maintain. Ideal for both maintenance and construction applications, the lift offers versatile performance on all jobsites.
Specifications
Manufacturer
Snorkel
Year
2026
Model
AB60J
Category
Material Handling Equipment
Subcategory
Boom Lifts
Overall length
8.87m
Overall width
2.4m
Weight
11,249kg
Max working height
20.1m
Max wind speed
12.5m/s
Controls
proportional joystick drive, lift & rotation
Max platform height
18.1m
Tires
15 in x 19.5 in foam filled
Clearance height at Max outreach
5.94m
Platform size
2.44m x 0.91m
Stowed height
2.51m
Ground clearance
300mm
Platform capacity (SWL)
227kg
Max drive speed (elevated)
0.96km/h
Max drive speed (stowed)
5.1 km/h
Raise / lower time
125 / 121 seconds
Jib length
1.8m
Superstructure rotation
360° continuous
Inside turning radius
5.24m
Outside turning radius
6.17m
Drive system
4 wheel drive
Jib arc
75°
Max drive height
18.1m
Max horizontal reach
13.1m
Gradeability
20%
Tailswing (riser boom elevated)
0m
Tailswing (riser boom stowed)
1.52m
Power source
Kubota V2403 48kW/65hp diesel - Tier 4 Final
