Description
The Snorkel 460SJ mid-sized telescopic boom lift was built to handle rough terrain. Fully proportional hydraulics deliver power and precision, and a jib offers flexibility on the job. The 460SJ also features powerful 4-wheel drive, minimal tailswing and 50% gradeability.
Specifications
Manufacturer
Snorkel
Model
460SJ
Year
2026
Category
Material Handling Equipment
Subcategory
Telescopic Boom Lifts
Max working height
16.0m
Max platform height
14.0m
Max horizontal reach
12.8m
Platform size
2.44m x 0.91m
Overall width
2.31m
Transport Length
6.55m
Transport Height
2.9m
Stowed height
2.38m
Ground clearance
320mm
Platform capacity - unrestricted
272kg
Platform capacity - restricted
454kg
Max drive height
14.0m
Max wind speed
12.5m/s
Max drive speed (elevated)
1.0km/h
Max drive speed (stowed)
6.8km/h
Raise / lower time
64 / 64 seconds
Gradeability
50%
Jib length
1.67m
Jib arc
135° (+70°/-65°)
Superstructure rotation
360° continuous
Tailswing
0.9m
Inside turning radius
3.0m
Outside turning radius
5.06m
Tires
355/55 D625 foam filled lug
Controls
proportional drive, raise, slew, extend, jib and platform rotate
Drive system
4 wheel drive
Power source
Kubota 18.6kW (24.9hp) diesel - Stage V
Auxiliary power unit
12V DC
