Description
SkyTrak 3013
Specifications
Manufacturer
SkyTrak
Model
3013
Year
2025
Category
Telehandlers
Subcategory
SkyTrak Telehandlers
Drawbar Pull
2623 lb / 1189.77 kg
Lift Capacity at Full Height
1555 lb / 705.34 kg
Lift Capacity at Max Reach
1200 lb / 544.31 kg
Maximum Lift Capacity
2700 lb / 1224.70 kg
Speed - Maximum Lift
10.9 sec
Speed - Maximum Lower
7.7 sec
Speed - Maximum Telescope In
4.5 sec
Speed - Maximum Telescope Out
7.5 sec
Speed - Maximum Travel
10.5 mph / 16.90 km/h
Capacity - Fuel Tank
14.5 gal / 54.89 L
Axle-Front
High Bias, Limited Slip
Axle-Rear
Oscillating
Function Pump Type
Gear
Operating Vehicle Weight
5280 lb / 2394.97 kg
Transmission - Nr Forward Gears Standard
1
Transmission - Nr Reverse Gears
1
Transmission Type
Hydrostatic
Load Center
2 ft / 0.61 m
Maximum Lift Height
13 ft 1 in / 3.99 m
Maximum Reach
7 ft 1 in / 2.16 m
Outside Turning Radius
9 ft 9 in / 2.97 m
Ground Clearance
10 in / 0.25 m
Machine Height
6 ft 7 in / 2.01 m
Machine Length
8 ft 9 in / 2.67 m
Machine Width
4 ft 7 in / 1.4 m
Tire Size
11 / 65 x 12 Pneumatic Ag Tread
Wheelbase
5 ft 7 in / 1.7 m
Engine Horsepower
24.8 hp / 18.50 kW
Engine Manufacturer
Kubota
Engine Model
V-1505
Maximum Engine RPM
2300 rpm
Hydraulic System Pressure
3988 psi / 279.28 Kg/cm2
