Description
The Snorkel S2255BE narrow rough terrain scissor lift delivers off-road performance anywhere. A bi-energy power system allows operators to switch between a diesel engine for outdoor work and zero emission battery power for indoor work. The dynamic S2255BE provides excellent versatility on the job, and is equipped with high grip non-marking tires as standard.
Specifications
Manufacturer
Snorkel
Model
S2255BE
Year
2025
Category
Material Handling Equipment
Subcategory
Scissor Lifts
Overall width
1.45m
Overall length
3.3m
Max working height
8.5m
Max platform height
6.5m
Stowed height
2.5m
Max drive height
6.5m
Platform size (stowed)
1.4m x 2.73m
Platform size (extended)
1.4m x 3.93m
Deck extension length
1.2m
Min height (guardrails folded)
2.0m
Ground clearance
260mm
Inside turning radius
2.5m
Outside turning radius
4.75m
Weight
2,780kg
Max wind speed
12.5m/s
Max drive speed (elevated)
0.66km/h
Max drive speed (stowed)
5.2 km/h
Tires
0.58m x 0.22m - 12 non-marking
Drive system
4 wheel drive
Power source
Bi-energy - Kubota diesel engine & 24V DC batteries
Platform capacity (SWL)
420kg
Raise / lower time
26 / 30 seconds
Controls
Proportional joystick
Gradeability (engine)
35%
