Description
The Snorkel S3970BE is the bi-energy version of the S3970RT rough terrain scissor lift. For the ultimate jobsite flexibility, operators can switch between a diesel engine and zero emission battery power. Compact with a roll-out deck extension and non-marking, high grip tires, the S3970BE suits all terrains.
Specifications
Manufacturer
Snorkel
Model
S3970BE
Year
2025
Category
Material Handling Equipment
Subcategory
Scissor Lifts
Max platform height
11.8m
Overall length
3.4m
Overall width
1.8m
Stowed height
2.95m
Min height (guardrails folded)
2.13m
Weight
4,090kg
Max wind speed
12.5m/s
Raise / lower time
50 / 60 seconds
Max drive speed (elevated)
0.3km/h
Max drive speed (stowed)
4.5km/h
Tires
27 x 10.5 - 15 foam filled non marking
Controls
proportional joystick
Drive system
4 wheel drive
Max working height
13.8m
Platform capacity (SWL)
350kg
Platform size (stowed)
1.6m x 2.8m
Platform size (extended)
1.6m x 4.0m
Deck extension length
1.2m
Ground clearance
330mm
Max drive height
11.8m
Gradeability (batteries)
25%
Inside turning radius
2.7m
Outside turning radius
5.0m
Gradeability (engine)
30%
Power source
Kubota D-902 water cooled diesel 22.5 hp - Tier 4 Final & 4 x 6v 305Ah batteries
